The type B connection (see diagram) looks more like a square, and connects to the end peripheral, such as a printer. The type A socket (see diagram) is rectangular in shape, and usually connects to the host or hub, typically a PC. USB is available in a multitude of connection types. However, the DVI to HDMI conversions will not be able to carry the 8 channel audio signal available on a pure HDMI connection, since DVI ports don't support audio. Since the conversion is a pin-to-pin connection, there should be no detectable signal loss when converted. 1.4 and 1.3), as well as with DVI devices for video sources. HDMI connections are backwards compatible among the various releases (i.e. Check the cable specifications to make sure it says 'high speed', '4K ready' or '18Gbps'. To watch 4K content on your device, the older 1.4 HDMI cable may or may not work. The CEC allows HDMI devices to control each other when necessary and allows the user to operate multiple devices with one remote control. HDMI supports any TV or PC video format, including standard, enhanced and high-definition video up to 8 channels of digital audio and a Consumer Electronics Control (CEC) connection. The HDMI 2.1 specification supersedes 2.0b but remains backwards compatible with previous versions. Dynamic HDR formats are also supported, and bandwidth capability is increased up to 48Gbps.
S video cable for mac update#
HDMI® Specification 2.1 is the most recent update of the HDMI specification and supports a range of higher video resolutions and refresh rates including 8K60 and 4K120, and resolutions up to 10K. The type, amount and speed of data HDMI carries expands with each HDMI release. It transmits uncompressed digital video and audio over a single, compact cable. HDMI stands for High-Definition Multimedia Interface.
Click here to download our Projector Connection diagram » HDMI Cables
